Linux Ubuntu 20.04 系统编译安装 Nginx

Linux Ubuntu 20.04 系统编译安装 Nginx

1.环境准备:

文件包:nginx-1.26.3.tar.gz

文件包下载地址:https://nginx.org/en/download.html

镜像源:https://developer.volcengine.com/articles/7109734973568974855

2.安装配置:

2.1 上传文件包并解压:
root@localhost:~# ls
nginx-1.26.3.tar.gz

root@localhost:~# tar -xf nginx-1.26.3.tar.gz                    ##解压nginx文件包

root@localhost:~# cd nginx-1.26.3/                               ##进入解压后的nginx目录内
2.2 安装依赖:
root@localhost:~#  apt-get update                                ##更新本地的软件包

root@localhost:~#  apt install build-essential libtool libpcre3  libpcre3-dev zlib1g-dev libssl-dev                                                       ##安装nginx所需要的依赖包
2.3 编译安装:
root@localhost:~#: ls                                            ##解压后的目录源文件
auto  CHANGES  CHANGES.ru  conf  configure  contrib  html  LICENSE  man  README  src

root@localhost:~#: ./configure --prefix=/usr/local/nginx --user=nginx --group=nginx --with-http_ssl_module --with-http_v2_module --with-http_realip_module --with-http_stub_status_module --with-http_gzip_static_module --with-pcre
																 ##编译安装

root@localhost:~#:	make && make install                         ##编译安装
编译安装配置项详解:
--prefix=/usr/local/nginx         ## 指定nginx部署目录
--user=nginx    --group=nginx     ## 指定nginx进程运行时使用的用户和组
--with-http_ssl_module            ## 启用 HTTPS/SSL 支持(80/443)
--with-http_v2_module             ## 支持 HTTP/2 协议,提示网页加载性能
--with-http_realip_module         ## 开启 显示客户端真实IP,如 CDN或者代理
--with-http_stub_status_module    ## 启用 Nginx 状态监控页面
--with-http_gzip_static_module    ## 启用 gzip 压缩
--with-pcre                       ## 启用 PCRE 库支持正则表达式
--with-http_rewrite_module        ## 支持 URL 重写
2.4 启动Nginx服务:
root@localhost:~# /usr/local/nginx/sbin/nginx                    ##启动nginx服务

root@localhost:~#  groupadd nginx                                ##创建nginx用户组

root@localhost:~#  useradd -g nginx -s /sbin/nologin nginx       ##创建nginx用户,并禁止登录

root@localhost:~#  ln -s /usr/local/nginx/sbin/nginx /usr/sbin/nginx  ##设置nginx软连接

root@localhost:~#  nginx                                         ##再次启动nginx服务

root@localhost:~#  nginx -V                                      ##查看nginx版本及模块

root@localhost:~#  netstat -nutlp | grep 80                      ##过滤nginx服务端口
2.5 nginx配置文件:
root@localhost:~#  vim /usr/local/nginx/conf/nginx.conf

#user  nobody;                                     # nginx服务运行时使用的用户
worker_processes  auto;                            # nginx工作进程数量

#error_log  logs/error.log;
#error_log  logs/error.log  notice;
#error_log  logs/error.log  info;                  # 错误日志路径,及输出日志等级
                                                   # info debug warn error

#pid        logs/nginx.pid;                        # nginx 进程ID文件位置

events{
	worker_connections  65535;       # 设置每个Worker进程能够同时处理的最大连接数,提示nginx并发
}

http {
    include mime.types;                 # 加载MIME类型定义文件(扩展名到Content-Type的映射)
    default_type application/octet-stream;         # 默认响应类型(二进制流,防文件直接下载)

    log_format main '$remote_addr - $remote_user [$time_local] "$request" '
                	'$status $body_bytes_sent "$http_referer" '
                	'"$http_user_agent" "$http_x_forwarded_for"';
                	                               # 日志输出格式

    access_log /dev/null;                          # 访问日志文件位置

    sendfile on;                                   # 启用零拷贝传输(提升静态文件性能)
    keepalive_timeout 65;                          # 客户端长连接保持65秒(减少TCP握手开销)

    ##gzip压缩配置
    gzip on;                                       # 启用Gzip压缩
    gzip_http_version 1.1;                         # 仅压缩HTTP/1.1及以上协议
    gzip_min_length 1k;                            # 只压缩大于1KB的文件
    gzip_buffers 4 16k;                            # 压缩缓冲区大小(4个16KB内存块)
    gzip_comp_level 9;                             # 最高压缩级别(CPU消耗较高)
    gzip_types text/plain [...]                    # 指定压缩的文件类型(覆盖了常见Web资源)
    gzip_vary on;                                  # 添加"Vary: Accept-Encoding"响应头
    gzip_disable "MSIE [1-6]\.";                   # 禁用IE6及以下版本的Gzip(兼容性)


    ##代理配置
    proxy_set_header Host $host;                   # 传递原始请求的Host头
	proxy_set_header X-Real-IP $remote_addr;       # 传递客户端真实IP
	proxy_set_header X-Forwarded-For $proxy_add_x_forwarded_for;  # 代理链IP记录
	proxy_set_header X-Forwarded-Proto $scheme;    # 原始协议(http/https)


	##跨域配置
	add_header 'Access-Control-Allow-Origin' *;    # 允许所有域跨域访问
	add_header 'Access-Control-Allow-Credentials' 'true';  # 允许携带Cookie
	add_header 'Access-Control-Allow-Methods' *;   # 允许所有HTTP方法
	add_header 'Access-Control-Allow-Headers' *;   # 允许所有请求头

	server {
    	listen 80;
    	server_name test.cn;                       # 匹配请求的Host头

        ##前端页面配置
    	location / {
      	    root /usr/local/nginx/html/test_kehu;  # 静态文件根目录
        	index index.html index.htm;            # 默认索引文件
        	try_files $uri $uri/ /index.html;      # 前端路由支持(如Vue/React)
    	}

        ##前端路由histroy模式
    	location /mobile {                         # 独立移动端路径
       	 	alias /usr/local/nginx/html/test_mobile;  # 注意:alias与root的区别
        	try_files $uri $uri/ /index.html;
    	}

        ##nginx状态监控页
    	location /nginx_status {                   # Nginx基础状态监控
      	 	stub_status;                           # 返回简版状态页
      	  	access_log off;                        # 不记录访问日志
      	    allow 127.0.0.1;                       # 建议添加IP白名单限制!
        	deny all;
    	}
	}


	server {
    	listen 443 ssl;
    	server_name test.cn;

        ##SSL证书配置
    	ssl_certificate ../cert/test.cn.pem;        # SSL证书路径(建议使用绝对路径)
    	ssl_certificate_key ../cert/test.key;       # SSL私钥路径
    	ssl_session_timeout 5m;                     # SSL会话缓存超时时间
    	ssl_protocols TLSv1.2 TLSv1.3;              # 仅允许安全协议(禁用TLSv1.0/1.1)
    	ssl_ciphers ECDHE+AESGCM:ECDHE+CHACHA20:...; # 现代加密套件
    	ssl_prefer_server_ciphers on;               # 优先使用服务端加密配置
   		ssl_session_cache shared:SSL:10m;           # SSL会话缓存(提升性能)

    	client_max_body_size 500M;                  # 允许上传大文件(如视频)

        ##80端口强制跳转443
    	add_header Strict-Transport-Security "max-age=31536000";  # 强制HTTPS(HSTS)
    	if ($server_port !~ 443){                   # HTTP自动跳转HTTPS
        	rewrite ^(/.*)$ https://$host$1 permanent;
   		 }

        ## 接口代理
    	location /oaapi/ {                          # 反向代理到后端Java服务
        	proxy_pass http://192.168.1.1:8080/;   # 注意末尾斜杠(会去除/oaapi前缀)
    	}

    	location /testapi/ {
    	   proxy_pass http://api/;
    	}

    	# 静态文件缓存至用户浏览器
    	location ~* \.(js|css|png|jpg|jpeg|gif|ico|svg)$ {
        	expires max;
        	log_not_found off;
    	}

    	## 永久重定向www到非www
   		if ($host = 'www.example.com') {
        	return 301 https://example.com$request_uri;
    	}

    	## 重定向旧域名到新域名
    	if ($host = 'old.example.com') {
        	return 301 https://example.com$request_uri;
    	}

    	# 重定向HTTP到HTTPS
		add_header Strict-Transport-Security "max-age=31536000; includeSubDomains" always;  # 强制HTTPS(HSTS)
    	if ($scheme != "https") {
        	return 301 https://$host$request_uri;
    	}
	}
		## 加权轮询代理
    	upstream api {
    	   server 192.168.0.1:8080   weight=2;
    	   server 192.168.0.2:8080   weight=1;
    	}
}

3.nginx命令及目录信息

3.1 nginx基础命令
root@localhost:~# nginx -t                          #检测配置文件格式

root@localhost:~# nginx -s reload                   # nginx热加载配置文件

root@localhost:~# nginx -s stop                     # 停止nginx服务

root@localhost:~# nginx -V                          # 查看版本及模块信息

## 如果未执行2.4里的软连接命令,会提示命令不存在,需执行绝对路径  /usr/local/nginx/sbin/nginx
3.2 nginx目录信息
/usr/local/nginx                                    # nginx服务目录
/usr/local/nginx/sbin/nginx                         # nginx可执行命令目录
/usr/local/nginx/conf                               # 默认配置文件目录,及SSL证书目录
/usr/local/nginx/conf/nginx.conf                    # 配置文件
/usr/local/nginx/html                               # nginx默认前端文件目录
/usr/local/nginx/logs                               # nginx日志文件目录
